Technical Specifications Category Specification Type Direct-Operated, Spring-Loaded Pressure Regulator Service Natural Gas, LP Gas, Inert Gases Size Range 3/4" to 2" NPT Maximum Inlet Pressure 5 psig (0.34 bar) for standard models Outlet Pressure Range 3" W.C. to 14" W.C. (0.75 kPa to 3.5 kPa) Temperature Range -20°F to 150°F (-29°C to 66°C) Body Materials Aluminum Diaphragm Material Fabric-Reinforced Elastomer Typical Applications Residential Gas Meter Sets Commercial Appliance Gas Supply LP Gas Vapor Service Industrial Pilot Lights & Small Burners Gas-Powered Equipment Regulation Secondary Pressure Reduction in Distribution Systems

Technical Specifications Category Specification Type Direct-Operated, Spring-Loaded Pressure Regulator Service Natural Gas, Manufactured Gas, LP Gas Vapor Size Range 3/4" to 2" NPT Maximum Inlet Pressure 5 psig (0.34 bar) for standard models Outlet Pressure Range 3" W.C. to 14" W.C. (0.75 kPa to 3.5 kPa) Temperature Range -20°F to 150°F (-29°C to 66°C) Body Materials Aluminum Diaphragm Material Fabric-Reinforced Elastomer Valve Seat Material Resilient seating material for positive shut-off Typical Applications Residential Gas Meter Sets Commercial Building Gas Service Industrial Appliance Gas Supply LP Gas Vapor Service Gas-Powered Equipment Regulation Pressure Reduction in Gas Distribution Systems Apartment House Gas Service

Technical Specifications Category Specification Type Volume Booster Relay, Force-Balance Input Signal 3 to 15 psig (0.2 to 1.0 bar) Output Signal 1:1 ratio of input, 3 to 15 psig Air Supply 20 psig (1.4 bar) minimum, up to 100 psig (6.9 bar) Flow Capacity High flow capacity; specific Cv values depend on model Accuracy Typically within ±0.5% of span Connections 1/4" or 1/2" NPT Body Material Cast Iron or Aluminum Typical Applications Speeding Up Large Actuators Long Pneumatic Signal Lines High-Capacity Signal Repeating Pneumatic Computing Circuits

Technical Specifications Category Specification Type Pilot-Operated High-Speed Relief Valve Service Gas, Liquid Set Pressure Range 15 to 6000 psig (1 to 413 bar) Temperature Range -450°F to 1000°F (-268°C to 538°C) Size Range 1" x 2" through 6" x 8" (inlet x outlet) Connections Flanged (150# to 2500#) Body Materials Carbon Steel, Stainless Steel, Alloy Steels Response Time < 100 milliseconds Leakage Bubble-tight up to 98% of set pressure Typical Applications Compressor Surge Protection Pipeline Surge Relief Pressure Vessel Protection Chemical Reactor Relief Gas Transmission Systems High-Pressure Process Protection

Technical Specifications Category Specification Type Pilot-Operated Pressure Regulator Service Natural Gas, Inert Gases Pressure Rating ANSI Class 600 (higher classes available) Size Range 2" through 6" (50 mm through 150 mm) Connections Flanged (RF or RTJ) Maximum Inlet Pressure Up to 1440 psig (99 bar) Outlet Pressure Range Configurable via pilot selection Temperature Range -20°F to 150°F (-29°C to 66°C) Body Materials Carbon Steel, Ductile Iron Trim Materials Stainless Steel (special materials available) Typical Applications High-Pressure City Gate Stations Industrial Plant Inlet Stations Pipeline Pressure Reduction Compressor Station Control Storage Field Regulation Gas Distribution Pressure Control

Technical Specifications Category Specification Type Pilot-Operated Pressure Regulator Service Natural Gas, Inert Gases Pressure Rating ANSI Class 150, 300, 600 Size Range 2" through 8" (50 mm through 200 mm) Connections Flanged (RF or RTJ) Maximum Inlet Pressure Up to 1440 psig (99 bar) depending on class Outlet Pressure Range Highly configurable via pilot selection Temperature Range -20°F to 150°F (-29°C to 66°C) Body Materials Ductile Iron (Standard), Carbon Steel Trim Materials Stainless Steel Typical Applications City Gate Stations Industrial Plant Inlets Pipeline Pressure Control Distribution System Regulation Storage Field Control Compressor Station Bypass Regulation

Technical Specifications Category Specification Type Direct-Operated, Spring-Loaded Pressure Regulator Service Natural Gas, LP Gas Size Range 3/4" to 2" NPT Maximum Inlet Pressure 5 psig (0.34 bar) for standard models Outlet Pressure Range 3" W.C. to 14" W.C. (0.75 kPa to 3.5 kPa) Temperature Range -20°F to 150°F (-29°C to 66°C) Body Materials Aluminum Diaphragm Material Fabric-Reinforced Elastomer Typical Applications Residential Gas Meter Sets Commercial Building Gas Service Industrial Appliance Gas Supply LP Gas Vapor Service Gas-Powered Equipment Regulation Secondary Pressure Reduction in Distribution Systems

Technical Specifications Category Specification Type Pneumatic Force-Balance Level Transmitter Input Hydrostatic head pressure Output 3-15 psig (0.2-1.0 bar) Air Supply 20-35 psig (1.4-2.4 bar) clean, dry air Accuracy ±0.5% of span Span Ranges Extended ranges with high suppression capability Temperature Range Elevated temperature capability beyond standard 63EG models Process Connections 2" NPT, 3" NPT, or flange connections Wetted Parts High-temperature materials (specific alloys depending on application) Diaphragm Material High-temperature compatible materials Case Material Aluminum or epoxy-coated cast iron Typical Applications High-Temperature Process Vessels Chemical Reactors with Thermal Cycling Boiler Drum Level Measurement Hot Oil Systems Refinery Process Units High-Pressure Steam Applications

Technical Specifications Category Specification Type Double-Acting Piston Actuator Action Double-Acting (Spring-Return optional with 66S module) Air Supply Pressure Up to 150 psig (10.3 bar) Operating Temperature -40°F to 180°F (-40°C to 82°C) Piston Diameter Multiple sizes available (e.g., 3.25 in, 4.5 in, 6 in) Stem Travel Multiple strokes available (e.g., 0.75 in to 4.0 in) Mounting Direct to Fisher 1060/1061 valves; other valves via linkage Body Material Aluminum (standard), Ductile Iron (for corrosive environments) Typical Applications Oil & Gas Production & Refining Chemical & Petrochemical Plants Power Generation Water & Wastewater Treatment General Process Industries

Technical Specifications Category Specification Type Pneumatic Displacer Level Controller Input Liquid level (buoyancy force) Output 3-15 psig (0.2-1.0 bar) Air Supply 20-35 psig (1.4-2.4 bar) clean, dry air Accuracy ±1% of span Span Ranges Various displacer lengths available Temperature Range Standard: -40°F to 450°F (-40°C to 232°C) High-temp: Up to 850°F (454°C) with special options Process Connections 2" NPT standard; 3" NPT and flanged options available Chamber Materials Carbon Steel, Stainless Steel Displacer Materials Stainless Steel, Hastelloy, other alloys Torque Tube Materials Various alloys for different service conditions Typical Applications Oil & Gas Separators Chemical Process Vessels Refinery Columns Boiler Drum Level Water Treatment Tanks High-Temperature Process Vessels Interface Level Applications
