Key Specifications
✔ Power Rating: 18.5 kW (25 HP)
✔ Input Voltage: 3-phase 380–480V AC (±10%), 50/60 Hz
✔ Output Current: 38 A
✔ Overload Capacity: 150% for 3 seconds
✔ Control Method: Sensorless Vector Control (DTC option available)
✔ Switching Frequency: 2–16 kHz (adjustable)
✔ Efficiency: >97.5%

Main Features
1. Advanced Motor Control
Direct Torque Control (DTC) for precise speed/torque regulation (±0.5% accuracy)

Automatic Motor Adaptation (AMA) – optimizes performance without encoder feedback

Torque boost & flying start – ensures smooth operation under heavy loads

2. Application-Specific Functions
Pre-programmed macros (pump, fan, conveyor, hoist)

Built-in PID controller for process automation

Customizable logic via free function blocks

3. Protection & Safety
Motor thermal protection (PTC/KTY input)

IGBT monitoring for short-circuit protection

Ground fault detection

Safe Torque Off (STO) – SIL3/PL e safety compliance

4. Connectivity & Control
Standard RS485 (Modbus RTU)

2 analog inputs (0–10V/4–20mA), 4 digital inputs, 2 relay outputs

Optional fieldbus adapters (PROFIBUS DP, DeviceNet, CANopen)

5. Robust Design
IP20 enclosure (dust protected)

Forced air cooling with temperature monitoring

Built-in EMC filter (Class A compliance)

Physical & Environmental Specs
Dimensions: 350 × 482 × 227 mm (W×H×D)

Weight: 12 kg

Cooling: Forced air (fan included)

Ambient Temp: -10°C to +50°C (14°F to 122°F)

Core Specifications
Drive Module (ACS800-04-0610-7):

Output Power: 610kW (400V configuration)

Output Current: 1180A continuous

Input Voltage: 3-phase 380-500V AC (±10%)

Overload Capacity:

110% continuous

150% for 60 seconds

Control Method: Direct Torque Control (DTC)

Efficiency: 98.5% at full load

Switching Frequency: 1-3kHz (adjustable)

P901 Control Panel:

10" high-brightness industrial touchscreen

Multi-language interface (20 languages)

Integrated web server with secure remote access

64GB data logging capacity

Dual USB 3.1 configuration ports

Real-time predictive maintenance functions

Key System Features
Advanced Performance:
✔ Ultra-Precise Control: ±0.01% speed accuracy
✔ Adaptive Control: 20 application-specific macros
✔ Process Optimization: Quad PID controllers with AI tuning
✔ Harmonic Mitigation: <3% THD with active front end

Connectivity & Integration:

Standard Interfaces:

4× 1Gbps Ethernet ports (PROFINET IRT, EtherNet/IP)

OPC UA over TCP/IP

IEC 61850 protocol support

Optional Modules:

PROFIBUS DP-V2

BACnet MS/TP

Wireless LAN module

Safety Systems:

SIL3/PL e certified safety functions:

Safe Torque Off (STO)

Safe Stop 1 (SS1)

Safe Speed Monitor (SSM)

Safe Brake Control (SBC)

Redundant safety processors

Continuous self-monitoring

Mechanical Specifications
Enclosure: IP21 (cabinet-mounted)

Cooling System: Liquid-assisted forced air cooling

Dimensions: 800 × 2200 × 600mm (W×H×D)

Weight: 450kg (complete system)

Noise Level: <70dB at 1m

Cooling Airflow: 3000m³/hr

The SIEMENS 6SE7012-0TP50-Z Z=C23+G91+K80 servo drive is a cutting-edge motor control solution, designed for applications requiring high precision and reliability in industrial automation environments.
