Technical Specifications Category Specification Type Pilot-Operated Pressure Regulator Service Natural Gas, Inert Gases Pressure Rating ANSI Class 150, 300 Size Range 2" through 6" (50 mm through 150 mm) Connections Flanged (RF or RTJ) Maximum Inlet Pressure Up to 400 psig (28 bar) depending on configuration Outlet Pressure Range Highly configurable via pilot selection Temperature Range -20°F to 150°F (-29°C to 66°C) Body Materials Ductile Iron (Standard), Carbon Steel Trim Materials Stainless Steel Typical Applications Town Border Stations Industrial Plant Inlets Pipeline Pressure Control Distribution System Regulation Commercial and Industrial Metering Stations

Technical Specifications Category Specification Type Pilot-Operated Pressure Regulator Service Natural Gas, Inert Gases Size Range 1/2" to 2" NPT Maximum Inlet Pressure 400 psig (28 bar) Outlet Pressure Range 3" W.C. to 200 psig (0.75 kPa to 14 bar) Temperature Range -20°F to 150°F (-29°C to 66°C) Body Materials Aluminum or Ductile Iron Leakage Class ANSI Class IV (metal seat) or Class VI (soft seat) Typical Applications Industrial Burner Trains Boiler Fuel Gas Control Process Heater Applications Gas Generator Sets Secondary Pressure Reduction Commercial and Industrial Metering & Regulation Stations

Technical Specifications Category Specification Type Pilot-Operated Pressure Regulator Service Natural Gas, Inert Gases Size Range 1/2" to 2" NPT Maximum Inlet Pressure 400 psig (28 bar) Outlet Pressure Range 3" W.C. to 125 psig (0.75 kPa to 8.6 bar) Temperature Range -20°F to 150°F (-29°C to 66°C) Body Materials Aluminum Leakage Class ANSI Class IV or VI Typical Applications Industrial Burner Control Boiler Fuel Systems Process Gas Applications Equipment Gas Supply Secondary Pressure Regulation Commercial Building Gas Systems

Technical Specifications Category H284 (P/P Transducer) H5114 (I/P Transducer) Type Pneumatic-to-Pneumatic Electro-Pneumatic Input Signal 3-15 psig (0.2-1.0 bar) 4-20 mA DC Output Signal 3-15 psig (0.2-1.0 bar) 3-15 psig (0.2-1.0 bar) Supply Pressure 20-100 psig (1.4-6.9 bar) 20-150 psig (1.4-10.3 bar) Accuracy ±0.5% of span ±0.5% of span Linearity ±0.5% of span ±0.5% of span Hysteresis ±0.1% of span ±0.1% of span Air Consumption < 1.0 SCFM < 0.5 SCFM Enclosure Rating NEMA 4X NEMA 4X Temperature Range -40°F to 180°F (-40°C to 82°C) -40°F to 180°F (-40°C to 82°C) Typical Applications H284: Control valve action reversal Pneumatic signal amplification Pneumatic computing circuits Signal inversion in control systems H5114: DCS/PLC to valve interface Pneumatic actuator control Process control systems Control valve positioning Modernization projects

Technical Specifications Category Specification Type Direct-Operated, Spring-Loaded Pressure Regulator Service Natural Gas, LP Gas Size Range 3/4" to 2" NPT Maximum Inlet Pressure 5 psig (0.34 bar) Outlet Pressure Range 3" W.C. to 14" W.C. (0.75 kPa to 3.5 kPa) Temperature Range -20°F to 150°F (-29°C to 66°C) Body Materials Aluminum Diaphragm Material Fabric-Reinforced Elastomer Typical Applications Residential Gas Meter Sets Commercial Building Gas Service Industrial Appliance Gas Supply LP Gas Vapor Service Gas-Powered Equipment Regulation Secondary Pressure Reduction in Distribution Systems

Technical Specifications Category Specification Type Pilot-Operated Pressure Regulator Service Natural Gas, Inert Gases Pressure Rating ANSI Class 150 Size Range 2" through 6" (50 mm through 150 mm) Connections Flanged (RF or RTJ) Maximum Inlet Pressure Up to 400 psig (28 bar) Outlet Pressure Range Configurable via pilot selection (e.g., inches of water column to psig ranges) Temperature Range -20°F to 150°F (-29°C to 66°C) Body Materials Ductile Iron (standard), Carbon Steel Trim Materials Stainless Steel Typical Applications Town Border Stations Industrial and Commercial Metering & Regulation Stations Pipeline Distribution Systems Pressure Reduction in Gas Distribution Networks Plant Inlet Supply Regulation Commercial Complex Gas Supply

Technical Specifications Category Specification Type Pilot-Operated Pressure Regulator Service Natural Gas, Inert Gases Pressure Ratings ANSI Class 150, 300, 600 Size Range 2" through 12" (50 mm through 300 mm) Connections Flanged (RF or RTJ) Maximum Inlet Pressure Up to 1440 psig (99 bar) depending on class Outlet Pressure Range Configurable from inches of water column to hundreds of psig Temperature Range -20°F to 150°F (-29°C to 66°C) Body Materials Carbon Steel (standard), Ductile Iron, Stainless Steel Trim Materials Stainless Steel with enhanced design Typical Applications City Gate Stations Industrial Plant Inlets Pipeline Pressure Control Storage Field Regulation Compressor Station Control Distribution System Pressure Reduction

Technical Specifications Category 6350 (Standard Capacity) 6360 (High Capacity) Type Electro-Pneumatic Transducer (I/P) Electro-Pneumatic Transducer (I/P) Input Signal 4-20 mA DC 4-20 mA DC Output Signal 3-15 psig (0.2-1.0 bar) 3-15 psig (0.2-1.0 bar) Supply Pressure 20-150 psig (1.4-10.3 bar) 20-150 psig (1.4-10.3 bar) Flow Capacity Standard capacity High capacity (approximately 2x 6350) Accuracy ±0.5% of span ±0.5% of span Linearity ±0.5% of span ±0.5% of span Hysteresis ±0.1% of span ±0.1% of span Air Consumption < 0.5 SCFM at steady state < 1.0 SCFM at steady state Enclosure Rating NEMA 4X NEMA 4X Temperature Range -40°F to 180°F (-40°C to 82°C) -40°F to 180°F (-40°C to 82°C) Typical Applications Control Valve Positioning Pneumatic Actuator Control Process Control Systems DCS and PLC Interface Pneumatic Instrumentation Systems Large Actuator Applications (6360) Fast-Response Control Systems (6360)

Technical Specifications Category Specification Type Direct-Operated, Spring-Loaded Pressure Regulator Service Natural Gas, LP Gas Size Range 3/4" to 2" NPT Maximum Inlet Pressure 5 psig (0.34 bar) Outlet Pressure Range 3" W.C. to 14" W.C. (0.75 kPa to 3.5 kPa) Temperature Range -20°F to 150°F (-29°C to 66°C) Body Materials Aluminum Diaphragm Material Fabric-Reinforced Elastomer

Technical Specifications Category Specification Type Pneumatic Force-Balance Level Transmitter Input Hydrostatic head pressure Output 3-15 psig (0.2-1.0 bar) Air Supply 20-35 psig (1.4-2.4 bar) clean, dry air Accuracy ±0.5% of span Span Ranges Adjustable over wide range Process Connections 2" NPT, 3" NPT, or flange connections Wetted Parts Stainless steel (standard), Monel, Hastelloy C Diaphragm Material Stainless steel with various lining options Case Material Aluminum or epoxy-coated cast iron Temperature Limits Standard: -40°F to 180°F (-40°C to 82°C)
