Key Parameters & Specifications Parameter / Feature Category Description Product Name Fisher™ FIELDVUE™ DVC6200p Digital Valve Controller Type Digital / Electro-Pneumatic Positioner (Smart) Primary Function To precisely position a control valve based on a control signal and provide advanced diagnostics and device information. Input Signal Analog: 4-20 mA DC, with HART 7 digital signal superimposed. Supply Pressure Up to 150 psig (10.3 bar). Output Pressure (to Actuator) Two Outputs: Independently controls two output pressures, making it ideal for double-acting piston actuators. Also supports single-acting piston and diaphragm actuators. Air Delivery Capacity High capacity for fast stroking of piston actuators. Typical volume gain: > 5.5 scfm (156 slpm). Communication Protocol HART 7 (4-20 mA with digital overlay). FOUNDATION™ Fieldbus and Profibus PA versions are available as separate models (DVC6200f & DVC6200pd). Pressure Sensors Integrated Sensors for monitoring supply pressure (S), and two output pressures (O1 and O2). Enclosure Rating NEMA 4X (IP66/67) for weather and water resistance. Certified for use in Hazardous Areas. Diagnostic Functions • Partial Stroke Test (PST) • Valve Performance Quick Check • Step Response Test • Travel & Pressure Trend • Friction & Deadband Analysis Actuator Compatibility • Double-Acting Piston (Primary) • Single-Acting Piston (Spring-Return) • Spring-and-Diaphragm

Parameters & Specifications Parameter / Feature Category Description Product Name Fisher™ D4 Easy-E™ Control Valve Type Top-Entry, Sliding Stem, Cage-Guided Globe Valve Primary Function Throttling (Modulating) Control for process fluids. Body Styles Globe Body: Straight-through flow pattern. Angle Body also available. Size Range (ANSI) ½ inch to 4 inches (DN 15 to DN 100) Pressure Rating (ANSI) Class 150, 300, 600 End Connections Flanged (Standard), Screwed, or Socket Weld Trim Cage-Guided, Non-Rotating Plug. A variety of trim trims are available (e.g., characterized cage, reduced trim, noise attenuation trim, anti-cavitation trim). Leakage Class ANSI Class IV (standard metal seat). ANSI Class VI (bubble-tight shut-off) is available with soft seat. Flow Characteristics Equal Percentage (Standard), Linear, Quick Opening (via characterized cage). Temperature Range Standard: -350°F to 450°F (-212°C to 232°C). Extended ranges available with special materials and seals. Actuator Compatibility Designed to be paired with Fisher pneumatic actuators (e.g., 657 or 667 diaphragm actuators) and a positioner (e.g., a FIELDVUE DVC or a pneumatic 3582).

Key Parameters & Specifications Parameter / Feature Category Description Product Name Fisher™ Yarway™ AT-37 / AT-47 Pneumatic Actuator Type Rack and Pinion, Quarter-Turn Pneumatic Actuator Primary Function To provide rotary torque for operating quarter-turn valves (ball, butterfly, plug). Actuator Type Double-Acting or Spring-Return (Fail-Safe). Supply Pressure Range Typically 40 to 120 psig (2.8 to 8.3 bar). Torque Output Varies with supply pressure. The AT-47 provides higher torque than the AT-37 at the same supply pressure. (Exact torque values in lb-in or Nm depend on the specific model and must be obtained from the data sheet). Standard Rotation 90° quarter-turn. Mounting Direct mounting to valves with ISO 5211 mounting pads. Can be fitted with a variety of mounting kits for specific valve brands. Position Indication Mechanical travel indicator (visual pointer) to show valve position (Open/Closed). Accessory Ports Prepared for the installation of accessories such as: Limit Switches (e.g., for position feedback) Solenoid Valves (for on/off pneumatic control) Positioners (e.g., Fisher 3720 for proportional control) | | Materials | Body: Aluminum or ductile iron. Internal Parts: Stainless steel and other corrosion-resistant materials. | | Temperature Range | Standard: -4°F to 180°F (-20°C to 82°C). Higher temperatures possible with special seals. |

Key Parameters & Specifications Parameter / Feature Category Description Product Name Fisher™ 3582 Pneumatic Valve Positioner Type Force-Balance, Cam and Lever, Pneumatic (I/P) Primary Application Positioning of rotary valves (ball, butterfly, plug) with piston actuators. Input Signal Standard: 3-15 psig (0.2-1.0 bar). Other input ranges (e.g., 6-30 psig) are available. Supply Pressure Up to 150 psig (10.3 bar). Output to Actuator Supply pressure dependent. Controls air to one or both sides of a piston actuator. Air Flow Capacity Very High. The large-volume relay is designed to quickly fill and exhaust the chambers of piston actuators. Typical exhaust capacity is >3.0 SCFM (85 slpm). Action Field-reversible between direct and reverse action. Feedback Mechanism Cam and Lever. Standard cams provide Linear or Equal Percentage flow characteristics. Actuator Compatibility Piston Actuators: • Double-acting (Primary use) • Single-acting (Spring-return) Mounting Direct-mounted to the actuator. Connects to the valve shaft via a feedback lever and link. Enclosure Weatherproof and corrosion-resistant aluminum enclosure. Approvals Suitable for use in hazardous areas due to its purely pneumatic design. Typically has FM, CSA, and ATEX certifications.

Key Parameters & Specifications Parameter / Feature Category Description Product Name Fisher™ easy-e™ EW Control Valve Type Top-Entry, Sliding Stem, Post-Guided Globe Valve Primary Function Throttling (Modulating) Control for general-purpose process applications. Body Styles Globe Body: Straight-through flow pattern. Angle Body also available. Size Range (ANSI) ½ inch to 2 inches (DN 15 to DN 50) Pressure Rating (ANSI) Class 150, 300 End Connections Flanged (Standard), Screwed, or Socket Weld Trim Post-Guided Plug. The plug is stabilized by a single guide post (bushing). Simpler than a cage-guided design. Leakage Class ANSI Class IV (standard metal seat). ANSI Class VI (bubble-tight shut-off) is available with a soft seat. Flow Characteristics Equal Percentage or Linear (determined by the contour of the plug). Temperature Range Standard: -20°F to 450°F (-29°C to 232°C). Extended ranges available with special materials. Actuator Compatibility Designed to be paired with Fisher pneumatic actuators (e.g., 657 or 667 diaphragm actuators) and a positioner (e.g., a FIELDVUE DVC or a pneumatic 3582).

Key Parameters & Specifications Parameter / Feature Category Description Product Name Fisher™ Baumann™ 81000 Series Pneumatic Actuator Type Spring-and-Diaphragm, Rotary Actuator (scotch yoke design) Primary Function To provide rotary torque for operating quarter-turn valves (ball, butterfly, plug). Actuator Type Double-Acting or Spring-Return (Fail-Safe). Housing Material Glass-Reinforced Polyamide (Plastic - Type 6.6 G). Corrosion-resistant and lightweight. Supply Pressure Range Typically up to 115 psig (8 bar). Torque Output Varies by size and supply pressure. The series includes multiple frame sizes (e.g., 81100, 81200, 81300, 81400) with increasing torque output. (Exact torque values in lb-in or Nm must be obtained from the specific size's data sheet). Standard Rotation 90° quarter-turn. Temperature Range -4°F to 180°F (-20°C to 82°C). Mounting Designed to mount to valves with ISO 5211 mounting pads. A variety of mounting kits are available for different valve brands and sizes.

Key Parameters & Specifications Parameter / Feature Category Description Product Name Fisher™ Vee-Ball™ V150 Control Valve Type Rotary Shaft, V-Port Ball Valve Primary Function Throttling and On/Off control of slurries, viscous fluids, and other challenging media. Size Range 3 inches to 16 inches (DN 80 to DN 400) Pressure Rating (ANSI) Class 150 End Connections Flanged (Standard: ANSI Class 150 RF). Wafer-style is also available for compact installation. Trim (Ball) Characterized V-Port Ball. The V-notch provides a precise flow characteristic and shearing action. Flow Characteristic Equal Percentage (inherent from the V-port shape). Leakage Class ANSI Class VI (Bubble-tight) with soft seats (V150S). ANSI Class IV with metal seats. Temperature Range With Soft Seats (V150S): Typically up to 400°F (204°C). With Metal Seats: Up to 1000°F (538°C). Actuator Compatibility Designed to be paired with piston actuators (e.g., Fisher 1061) or spring-diaphragm rotary actuators for automatic control. Typically equipped with a positioner like the Fisher 3582 or a FIELDVUE DVC.

Key Parameters & Specifications Parameter / Feature Category Description Product Name Fisher™ 4195K Pneumatic Actuator Type Spring-and-Diaphragm, Scotch-Yoke, Rotary Actuator Primary Function To provide rotary torque for operating quarter-turn valves (ball, butterfly, plug). Actuator Type Spring-Return (Fail-Safe). Double-acting models are available in the 4195 series without the "K" suffix. Input Signal Standard: 3-15 psig (0.2-1.0 bar) or 6-30 psig (0.4-2.0 bar). Supply Pressure Up to 100 psig (7 bar) for the spring-return model. Housing Material Aluminum (corrosion-resistant). Torque Output Provides high torque output. Exact values depend on the actuator size (e.g., 60, 70, 80, 90, 100) and supply pressure. (Consult the specific data sheet for torque curves). Standard Rotation 90° quarter-turn. Action Field-reversible between direct and reverse action. Fail-Safe Action Spring-Return. The valve fails to the position determined by the actuator orientation (fail-open or fail-close). Temperature Range Standard: -20°F to 180°F (-29°C to 82°C) with standard lubricant and seals. Mounting Designed to mount to valves with ISO 5211 mounting pads. Uses a standardized mounting kit system. Accessory Ports Prepared for the installation of accessories such as: • Limit Switches • Solenoid Valves • Positioners (e.g., Fisher 3582 or a FIELDVUE DVC)

Key Parameters & Specifications Parameter / Feature Category Description Product Name Fisher™ 585C Series Pneumatic Actuator Type Spring-and-Diaphragm, Linear (Sliding-Stem) Actuator Primary Function To provide linear thrust for operating sliding-stem control valves (e.g., globe valves). Actuator Type Spring-Return (Fail-Safe). Input Signal Standard: 3-15 psig (0.2-1.0 bar) or 6-30 psig (0.4-2.0 bar). Supply Pressure Typically up to 100 psig (7 bar) for the spring-return model. Action Field-reversible between direct-acting and reverse-acting. Fail-Safe Action Spring-Return. The valve fails to the position determined by the action (e.g., direct-acting fails open, reverse-acting fails closed). Diaphragm Material Nitrile (standard). Other materials like EPDM, Viton® are available for different temperature and fluid compatibility. Spring Ranges Multiple spring ranges are available to match the required thrust for different valve sizes and pressure drops. Stem Travel Available in various standard strokes (e.g., 3/4", 1-1/2", 2-1/2", 3-1/2"). Enclosure NEMA 4X (IP66) molded cover is standard, providing weatherproof and corrosion-resistant protection. Mounting Directly mounts to the yoke of Fisher and other compatible sliding-stem control valves. Accessory Mounting The yoke and cover are designed to mount accessories like: • Positioners (e.g., Fisher 480, FIELDVUE DVC) • Limit Switches • Transducers (I/P) • Solenoid Valves

Key Parameters & Specifications Parameter / Feature Category Description Product Name Fisher™ V500 Vee-Ball® Control Valve Type Rotary Shaft, V-Port Ball Valve Primary Function Throttling and On/Off control of slurries, viscous fluids, and other general service media. Size Range 1 inch to 12 inches (DN 25 to DN 300) Pressure Rating (ANSI) Class 150 End Connections Flanged (Standard: ANSI Class 150). Wafer-style is also available for a more compact installation. Trim (Ball) Characterized V-Port Ball. Flow Characteristic Equal Percentage (inherent from the V-port shape). Leakage Class ANSI Class VI (Bubble-tight) with soft seats. ANSI Class IV with metal seats. Temperature Range With Soft Seats: Typically up to 400°F (204°C). With Metal Seats: Up to 1000°F (538°C). Actuator Compatibility Designed to be paired with piston actuators (e.g., Fisher 1061) or spring-diaphragm rotary actuators (e.g., Fisher 4195) for automatic control. Typically equipped with a positioner like the Fisher 3582 or a FIELDVUE DVC.
