Technical Parameters Parameter Specification Model Fisher 2052 Type Spring-Loaded, Full Nozzle Safety Relief Valve Service Liquid, Steam, or Air/Gas Operation Standard (Non-Balanced) Body Materials Cast Iron (Standard for general service), Bronze, Carbon Steel, Stainless Steel End Connections Flanged (ANSI Class 125 & 150); Screwed (NPT) Orifice Designation & Area Sizes from D (0.110 in²) to T (6.380 in²) and larger, per ASME/API standards. Size Range (Inlet) 1" x 2" to 8" x 10" (e.g., 1" inlet, 2" outlet) Pressure Rating Up to 375 psig (26 bar) for Cast Iron bodies. Higher pressures with steel bodies. Temperature Limits -20°F to 450°F (-29°C to 232°C) with standard Buna-N elastomers. Higher temps with special materials. Set Pressure Range Varies by orifice size and spring. Available in a wide range, from a few psig to hundreds of psig. Backpressure Tolerance Limited (typically < 10% of set pressure) due to standard (non-balanced) bellows design. Standards Designed to meet ASME Section VIII and API 526 standards.

Technical Parameters Parameter Specification / Options Platform Fisher easy-e™ ES (Enhanced Series) Globe Valve Body Style Globe, Angle, 3-Way Bonnet Style Standard, Extension (for high/low temperatures), Bellows Seal End Connections Flanged - ANSI Class 150, 300, 600; Butt-Weld; Screwed Body Materials Carbon Steel (WCB), Stainless Steel (CF8/CF8M), Alloy Steel Size Range 1/2" to 8" (DN 15 to DN 200) Pressure Rating ANSI Class 150, 300, 600 (up to 1440 psig / 99 bar) Temperature Range Standard: -40°F to 450°F (-40°C to 232°C) Extended: -320°F to 1000°F (-196°C to 538°C) with special bonnets Leakage Class ANSI Class IV (Metal Seat) or ANSI Class VI (Soft Seat) Flow Characteristic Equal Percentage, Linear, Quick Opening Trim Types Micro-Form™ (Standard), Whisper Trim® III (Noise Control), Anti-Cavitation Trim Actuator Compatibility Fisher 657 & 667 Diaphragm Actuators,

Technical Parameters Parameter Specification Model Yarway AT-18 Yarway AT-28 Type Pilot-Operated Inverted Bucket Steam Trap Operation Continuous Discharge Connection Screwed (NPT) Body Material Forged Carbon Steel (Standard), Ductile Iron Internal Parts Stainless Steel Maximum Working Pressure 200 psig (14 bar) 450 psig (31 bar) Maximum Working Temperature 450°F (232°C) 800°F (427°C) Orifice Size 0.094" (2.4mm) Air Vent Balanced Pressure Thermostatic Bellows (for fast air removal) Capacity (lbs/hr of condensate) Varies with pressure differential. Example (at 100 psig ΔP): ~ 640 lbs/hr

Technical Parameters Parameter Specification Model / Technology Fisher DMA (Metal) Fisher AF (Fluoropolymer-Coated) Type Multi-Stage Anti-Cavitation & Noise Attenuation Trim Primary Function Cavitation Control & Noise Reduction Corrosion Resistance & Cavitation Control Trim Construction Stacked metal plates/disks with micro-perforations. Metal core with a thick, inert fluoropolymer coating (e.g., PTFE, PFA). Wetted Materials Stainless Steel (Standard), other alloys like Hastelloy®. Carbon Steel or Stainless Steel core with PTFE or similar Fluoropolymer coating. Pressure Drop Capability Capable of handling very high pressure drops (ΔP), often in excess of 1000 psi. Noise Reduction Can achieve up to 15-20 dBA or more of noise attenuation. Compatible Valve Bodies Fisher easy-e® (e.g., 1077, 1098), V500, V100, V200, and others. Size Range Designed to fit valve sizes from 1" to 12" (DN 25 to DN 300) and larger. Temperature Limits Depends on material, but standard metal DMA can handle up to 800°F (427°C) or more. Limited by the polymer, typically up to 400°F (204°C) for PTFE. Standards Compliant with NACE MR0175/ISO 15156 for sour service (material dependent).

Technical Parameters Parameter Specification Model Fisher Vee-Ball V300 Type Rotary V-Notch Ball Control Valve Flow Characteristic Equal Percentage (inherent from the V-notch profile) Shut-Off Class ANSI Class VI (Bubble-tight) with standard non-metallic seats. End Connections Flanged (ANSI Class 150 & 300) Body Materials Carbon Steel (WCB), Stainless Steel (CF8, CF8M), Alloy 20 Ball & Stem Material Stainless Steel (standard), with hard-facing (e.g., Stellite) options for abrasive service. Seat Material Reinforced PTFE (RPTFE) is standard. Other materials like UHMW-PE are available. Temperature Range -40°F to 400°F (-40°C to 204°C) with standard RPTFE seats. Pressure Rating ANSI Class 150: 275 psig (19 bar) ANSI Class 300: 720 psig (49.6 bar) Flow Capacity (Cv) Varies by size. Example (Class 150 Flanged): - 3 inch: ~ 290 - 6 inch: ~ 1150 - 8 inch: ~ 2050 Sizes (Pipe Size) 1" to 12" (DN 25 to DN 300)

Key Parameters & Specifications Parameter / Feature Category Description Product Name Fisher™ QUIKLOOK 3-FS Portable Communicator / Calibrator Primary Application Configuration, calibration, and diagnostics of Fisher FIELDVUE® digital valve controllers, DVC series positioners, and other HART communication protocol devices. Communication Protocol HART (Highway Addressable Remote Transducer) Protocol. Display Backlit LCD screen for displaying menus, parameters, and graphical data. Input / Control Keypad for navigation and data entry. Power Supply Uses replaceable alkaline batteries or a rechargeable battery pack. Pressure Measurement • Ranges: Typically features two built-in pressure sensors (e.g., one high range like 0-750 psi / 0-52 bar, and one low range like 0-150 psi / 0-10 bar) for precise measurement of pneumatic actuator supply and output pressures. • Accuracy: Typically ±0.1% of reading or better. Current Measurement • Range: Measures the 4-20 mA analog input/output signal. • Accuracy: Typically ±0.025% of reading or better. Current Sourcing / Simulation Can source and simulate a 4-20 mA signal to test valve travel or controller output. Pressure Control / Simulation Does not have a built-in pressure pump or regulator to control air pressure. It is primarily used for measuring and monitoring pressure, not for generating it. An external air supply is required for testing. Valve Testing & Diagnostic Functions • Auto/Manual Stroke Testing: For calibrating valve zero and span. • Step Response Test: Evaluates the dynamic response performance of the valve assembly. • Friction Test: Diagnoses packing and actuator friction. • Travel Deviation Monitoring: Monitors and records deviations from the expected valve position. Software & Data Management Capable of storing device configurations and test results. Data can often be transferred to a computer for further analysis and record-keeping. Environmental Rating Typically rated for use in harsh industrial environments and may have certifications for use in hazardous areas.

Key Parameters & Specifications Parameter / Feature Category Description Product Name Fisher™ 480 Series Pneumatic Valve Positioner Type Force-Balance, Pneumatic (I/P) Primary Function To accurately position a control valve stem in proportion to a pneumatic input signal. Input Signal Standard: 3-15 psi (0.2-1.0 bar) or 6-30 psi (0.4-2.0 bar). Other ranges are available. Output Signal (to Actuator) Supply pressure dependent. Provides the necessary air pressure to the actuator to achieve and hold the required valve position. Supply Pressure Typically up to 100 psig (7 bar) for the 48000 model. Other models may vary. Must be at least 3-5 psi above the input signal and actuator pressure requirements. Action Field-reversible between direct and reverse. • Direct: Input signal increase extends stem (for air-to-open valves). • Reverse: Input signal increase retracts stem (for air-to-close valves). Air Consumption Low, typically around 0.15 SCFM (4 standard liters/min) at steady state. Flow Capacity (Relay) High-capacity relay allows for rapid filling and exhausting of the actuator. Typical exhaust capacity is >1.0 SCFM (28 standard liters/min). Mounting Direct-mounted on the valve yoke, with a mechanical feedback linkage connected to the valve stem. Enclosure Generally, a weatherproof and corrosion-resistant aluminum enclosure. Approvals Suitable for use in hazardous areas due to its purely pneumatic nature. Typical Models 48000 (general purpose), 48001, 48002, etc., with variations for specific actuator types and linkages.

Key Parameters & Specifications Parameter / Feature Category Description Product Name Fisher™ 461 Series Pneumatic Force-Balance Indicator / Transmitter Type Pneumatic Force-Balance Transmitter & Local Indicator Primary Function To provide a local visual indication of a process variable (pressure, level) and/or transmit a proportional pneumatic signal to a control room. Input (Process) Pressure: Various ranges, commonly from 0-30" H₂O (0-7.5 kPa) up to 0-800 psig (0-55 bar). Level: For liquid level applications, using the hydrostatic head pressure. Output Signal Standard Pneumatic Signal: 3-15 psig (0.2-1.0 bar). Supply Pressure Standard: A clean, regulated air supply of 20 psig (1.4 bar) is typical. Must be higher than the output signal (e.g., >18 psig). Accuracy Typically ±0.5% of span for the indicating scale. Scale Large, easy-to-read dial. Can be calibrated in various engineering units (psi, kPa, inches of water, % level, etc.). Operation Two-Wire Pneumatic System: A single supply air line powers the device, and the output signal is superimposed on this supply, varying between 3 and 15 psig. Mounting Direct mounting to a process connection (e.g., a tank nozzle or pipe tap) or to a manifold. Enclosure Rugged, weather-resistant aluminum case with a glass or plastic window. Key Models & Versions • 461: General purpose indicator/transmitter. • 461L: Specifically designed for liquid level measurement. • 461R: Functions as a receiver to display a remote 3-15 psi signal locally.

Key Parameters & Specifications Parameter / Feature Category Description Product Name Fisher™ 3720 Series Pneumatic Valve Positioner Type Force-Balance, Pneumatic (I/P), Cam and Lever Primary Application Positioning of rotary valves (ball, butterfly, plug) with piston actuators. Input Signal Standard: 3-15 psig (0.2-1.0 bar). Other input ranges are available. Supply Pressure Up to 150 psig (10.3 bar). Must be sufficient to meet the actuator's pressure requirements. Output to Actuator Supply pressure dependent. Provides controlled air pressure to one or both sides of the piston actuator. Action Field-reversible between direct and reverse action. Feedback Mechanism Cam and Lever. The cam profile is designed to linearize the relationship between the input signal and the valve's rotational travel. Flow Capacity (Relay) High-capacity relay for fast filling and exhausting of piston actuators, ensuring quick valve response. Mounting Direct-mounted to the actuator. Connects to the valve shaft via a feedback lever and link. Enclosure Weatherproof and corrosion-resistant aluminum enclosure. Actuator Compatibility Piston Actuators: • Double-acting • Single-acting (spring-return) Approvals Suitable for use in hazardous areas due to its purely pneumatic design. Can have specific certifications like FM, CSA, ATEX, etc.

Key Parameters & Specifications Parameter / Feature Category Description Product Name Fisher™ DST-G Digital Sliding Gate™ Control Valve Assembly Type Integral Assembly of a rotary-shaft control valve body, Sliding Gate trim, and a digital valve positioner. Primary Function High-performance throttling control with integrated digital diagnostics and configuration. Trim Technology Sliding Gate™ Trim: A non-rotating stem moves a ported disc across a fixed seat. This design minimizes friction and wear. Actuator & Positioner Actuator: Spring-and-diaphragm or piston actuator. Positioner: Typically integrated with a Fisher FIELDVUE® (e.g., DVC6000 or DVC2000) Digital Valve Controller as a standard feature. Communication & Protocol HART®, FOUNDATION™ Fieldbus, or Profibus PA (depending on the DVC version ordered). Flow Characteristics Equal Percentage is standard. Linear characteristic is available. Valve Body Styles Fisher Vee-Ball® (most common for DST-G), Fisher easy-e® Control Valve, or Fisher GX Control Valve. Size Range (Vee-Ball) Typically 1 to 12 inches (DN 25 to DN 300). Pressure Rating (ANSI) Class 150 through Class 600. Leakage Class ANSI Class IV (standard metal-seated). ANSI Class VI (soft-seated) is available for bubble-tight shut-off. Temperature Range Standard: -50°F to 450°F (-46°C to 232°C). Extended temperature ranges are available with special components. Key Features • High Capacity: High Cv for a given valve size. • Low Fugitive Emissions: Packing system designed for low emissions. • Smart Diagnostics: Built-in diagnostics via the FIELDVUE positioner (e.g., travel, pressure, step-response tests). • Stable Control: Non-rotating guide design provides exceptional stability, reducing deadband and hysteresis.
