Key Specifications
Parameter Specification
Output Current 12A
Rated Power 5.5kW (400V, 4-pole motor)
Input Voltage 3-phase 380–480V AC (±10%), 50/60Hz
Enclosure IP21 (open chassis, panel-mountable)
Control Method Flux-optimized V/f & DTC (Sensorless Vector)
Overload 150% for 60 seconds
Communication Modbus RTU (RS485), optional fieldbus
Key Features
✔ Energy-Saving Control – Automatic motor adaptation reduces energy consumption by up to 30% in pump/fan applications.
✔ Intuitive Operation – Assist Panel with plain-text parameter names (no codes).
✔ Built-in Safety – Safe Torque Off (STO, SIL3/PL e) for emergency stops.
✔ Smart Cooling – Temperature-controlled fan (IP21) with low acoustic noise.
✔ Fieldbus Ready – Supports PROFIBUS DP, BACnet MS/TP, Ethernet/IP (via adapters).
✔ Robust Protection – Motor thermal protection, short-circuit, and phase-loss safeguards.

Model Number Breakdown
ACS580: Series (ABB’s general-purpose drive)

01: IP21 enclosure (basic protection)

12A7: 12A output current, 5.5kW power class

4: 400V voltage range (380–480V)
