Core Function:
Ruggedized dual-channel monitoring system designed for extreme industrial environments, measuring:
✓ Vibration (velocity/displacement)
✓ Shaft position
✓ Rotational speed

Key Specifications:
• Input Channels: 2 fully independent
• Measurement Ranges:

Vibration: 0-500 µm pk-pk

Displacement: 0-2.0 mm

Speed: 0-20,000 RPM
• Sampling Rate: 1kHz per channel

Ruggedized Design:
✓ IP66 rated enclosure
✓ -40°C to +85°C operation
✓ 5g vibration resistance (10-500Hz)
✓ ATEX/IECEx certified options

Output & Communication:

2x isolated 4-20mA outputs

4x alarm relays (SPDT)

RS-485 Modbus + Ethernet option

Typical Applications:

Offshore oil & gas platforms

Mining and heavy machinery

Mobile equipment monitoring

Hazardous area installations

Configuration:
Intuitive LCD interface or CMS 2000 software

Compliance:
API 670, ISO 10816 standards

Special Features:

Dual-channel redundancy

Extended temperature operation

Corrosion-resistant housing

Core Function:
Industrial eddy current sensor for wide-range displacement monitoring in heavy rotating equipment

Key Specifications:
• Sensitivity: 3.0 mV/µm (±5%)
• Extended Range: 0-3.0mm (3000µm)
• Frequency Response: DC to 10kHz
• Output: -2 to -20V DC linear signal

Mechanical Configuration:
✓ 8mm diameter probe
✓ M10×1 threaded mounting
✓ Operating temperature: -30°C to +120°C
✓ Vibration resistant to 20g

Measurement Performance:

Target material: AISI 4140 steel

Linear operating range: 60% of full scale

Typical accuracy: ±1% FS

System Integration:
• Compatible with EPRO MMS6000 monitoring systems
• Standard 5m/9m cable options
• CON021 quick-disconnect available

Typical Applications:

Large turbine shaft monitoring

Compressor thrust bearing measurement

Heavy industrial machinery protection

Special Features:

Optimized for wide displacement range applications

Special variant (/002) with enhanced environmental tolerance

Compliance: Meets API 670 machinery protection standards

Core Function:
Industrial eddy current sensor for vibration and displacement monitoring in rotating machinery

Key Specifications:
• Sensitivity: 4.0 mV/µm (±5%)
• Measurement Range: 0-2.0mm (2000µm)
• Frequency Response: DC to 10kHz
• Output Signal: -2 to -20V DC (linear)

Mechanical Design:
✓ 8mm diameter probe
✓ M10×1 threaded mounting
✓ Operating temperature: -30°C to +120°C
✓ Vibration resistant to 20g

Measurement Performance:

Target material: AISI 4140 steel

Linear operating range: 60% of full scale

Typical accuracy: ±1% of full scale

System Integration:
• Compatible with EPRO MMS6000 monitoring systems
• Standard 5m/9m cable options
• CON021 quick-disconnect available

Typical Applications:

Turbine shaft vibration monitoring

Compressor axial position measurement

Rotating equipment protection systems

Compliance: Meets API 670 machinery protection standards

Special Feature:
Optimized for medium-range displacement measurements with stable output in harsh environments

Core Function:
Industrial eddy current sensor designed for wide-range displacement and vibration monitoring in heavy rotating equipment.

Key Specifications:
• Sensitivity: 2.1 mV/µm (±5%)
• Extended Range: 0-2.1mm (2100µm)
• Frequency Response: DC to 10kHz
• Output: -2 to -20V DC linear signal

Mechanical Configuration:
✓ 8mm diameter probe
✓ M10×1 threaded mounting
✓ Operating temperature: -30°C to +120°C
✓ Vibration resistant to 20g

Measurement Performance:

Target material: AISI 4140 steel

Linear operating range: 60% of full scale

Typical accuracy: ±1% FS

System Integration:
• Compatible with EPRO MMS6000 monitoring systems
• Standard 5m/9m cable options
• CON021 quick-disconnect available

Typical Applications:

Large turbine shaft monitoring

Compressor thrust bearing measurement

Heavy industrial machinery protection

Special Features:

Optimized for wide displacement range applications

Maintains stability in high-vibration environments

Compliance: Meets API 670 machinery protection standards

Core Function:
High-sensitivity eddy current displacement sensor for precision machinery monitoring

Key Specifications:
• Sensitivity: 12.0 mV/µm (±5%)
• Measurement Range: 0-1.2mm (1200µm)
• Frequency Response: DC to 10kHz
• Output: -2 to -20V DC (linear analog)

Mechanical Configuration:
✓ 8mm diameter probe
✓ M10×1 threaded mounting
✓ Operating temperature: -30°C to +120°C
✓ Vibration resistance: 20g (50Hz)

Measurement Performance:

Target material: AISI 4140 steel

Linear range: 60% of full scale

Accuracy: ±1% of full scale

System Integration:
• Compatible with EPRO MMS6000 monitors
• Standard 5m/9m cable options
• CON021 quick-disconnect available

Typical Applications:

Turbine shaft vibration monitoring

Compressor thrust position measurement

Precision bearing clearance monitoring

Compliance: API 670 machinery protection standard

Special Feature:
Enhanced 12.0 mV/µm sensitivity provides superior resolution for detecting minute displacement changes in critical equipment.

Key Specs:

Type: 3-axis IEPE accelerometer

Sensitivity: 100mV/g (X/Y), 50mV/g (Z)

Frequency Range: 0.5Hz-8kHz

Measurement Range: ±50g (X/Y), ±100g (Z)

Rugged Design:

Titanium alloy housing

M5 military-grade mounting

IP68 submersible rating

10,000g shock survival

Performance:

<3% cross-axis sensitivity

-55°C to +150°C operation

MIL-DTL-38999 connector

Applications:

Aerospace structural testing

Military/defense systems

Harsh industrial environments

Core Function:
Industrial vibration sensor for machinery condition monitoring, measuring:
✓ Acceleration (±50g range)
✓ Velocity (via signal integration)

Key Specifications:
• Sensitivity: 10 mV/g (±5%)
• Frequency Range: 0.5Hz-5kHz
• Output: Voltage mode (requires 18-30V DC excitation)
• Accuracy: ±1% typical

Robust Design:
✓ Stainless steel housing
✓ IP67 protection rating
✓ M6 threaded mounting
✓ -40°C to +120°C operation

Measurement Performance:

Linear range: ±50g peak

Resonant frequency: >25kHz

Transverse sensitivity: <5%

Typical Applications:

Motor/pump bearing monitoring

Compressor vibration analysis

Gearbox condition assessment

System Integration:
• Compatible with EPRO MMS6000 systems
• Standard 5m integral cable
• Requires signal conditioner (e.g., CON051)

Compliance: Meets ISO 10816 and API 670 standards

Core Function:
Industrial-grade eddy current sensor for extended-range displacement monitoring in heavy machinery applications.

Key Specifications:
• Sensitivity: 3.0 mV/µm
• Wide Measurement Range: 0-3.0mm (3000µm)
• Output Signal: -2 to -20V DC linear output
• Frequency Response: DC to 10kHz

Robust Design Features:
✓ 8mm diameter probe with M10×1 threading
✓ Extended temperature operation (-30°C to +120°C)
✓ Vibration resistant up to 20g
✓ Ruggedized cable/connector options (/10R variant)

Measurement Performance:

Target Material: Mild steel (AISI 4140)

Linear Range: Middle 60% of full scale

Accuracy: ±1% of full scale

Typical Applications:

Large turbine shaft vibration monitoring

Compressor thrust position measurement

Heavy industrial machinery protection

System Integration:
• Compatible with EPRO MMS6000 monitoring systems
• Standard 5m/9m cable lengths available
• CON021 quick-disconnect option

Compliance: Meets API 670 machinery protection standards

Core Function:
Advanced dual-channel monitoring system for critical machinery protection, measuring:
✓ Vibration (velocity/displacement)
✓ Shaft position (via proximity probes)
✓ Rotational speed

Key Features:
• Dual Input Channels – Supports eddy current, velocity, and tachometer signals
• Measurement Ranges:

Vibration: 0-500 µm

Displacement: 0-2.0 mm

Speed: 0-20,000 RPM
• Protective Outputs:

2x 4-20mA analog signals

4x alarm relays (Danger/Warning)

RS-485/Modbus + optional Ethernet

Technical Specs:

Power: 24V DC or 100-240V AC

Operating Temp: -20°C to +70°C

Compliance: API 670, ISO 10816

Typical Applications:

Steam/gas turbine monitoring

Compressor protection systems

Critical pump vibration analysis

Configuration:
Intuitive setup via front panel or EPRO CMS 2000 software

Core Function:
Compact 5mm eddy current sensor for precision vibration and displacement monitoring in tight spaces.

Key Specifications:
• Sensitivity: 8.0 mV/µm (standard calibration)
• Measuring Range: 0-1.0mm (1000µm)
• Frequency Response: DC to 10kHz
• Output: -2 to -20V linear analog signal

Mechanical Details:
✓ 5mm diameter probe (smallest in PR6400 series)
✓ M8×1 threaded mounting
✓ Operating Temp: -30°C to +120°C
✓ Vibration resistant up to 20g

Typical Applications:

Small motor/compressor shaft monitoring

Precision bearing clearance measurement

Space-constrained machinery installations

System Integration:
• Compatible with EPRO MMS6000 monitors
• Standard 5m/9m cable options
• CON021 quick-disconnect available

Compliance: Meets API 670 machinery protection standards
