FISHER™ MR98
Technical Specifications
Category Specification
Type Pilot-Operated, Balanced Trim Pressure Regulator
Service Natural Gas, Inert Gases
Pressure Rating ANSI Class 150, 300, 600
Size Range 2" through 12" (50 mm through 300 mm)
Connections Flanged (RF or RTJ)
Maximum Inlet Pressure Up to 1440 psig (99 bar), depending on body class and trim.
Outlet Pressure Range Highly configurable via pilot selection, from inches of water column to several hundred psig.
Temperature Range -20°F to 150°F (-29°C to 66°C)
Body Materials Ductile Iron (Standard), Carbon Steel, Stainless Steel
Trim Materials Stainless Steel
Typical Applications
City Gate Stations
Town Border Stations
Industrial Plant Inlet Stations
Pipeline Pressure Reduction
Underground Storage Field Control
Compressor Station Bypass Control
