High quality FANUC A06B-6078-H206#H500 servo amplifier, original new & refurbished available. Factory warranty, worldwide delivery, competitive price for industrial automation.
home
High quality FANUC A06B-6078-H206#H500 servo amplifier, original new & refurbished available. Factory warranty, worldwide delivery, competitive price for industrial automation.
WhatsApp
Product Name: FANUC ALPHA Spindle Amplifier Module (Model SPM-5.5)Part Number: A06B-6078-H206#H500
Brand: FANUC
Type: Alpha Spindle Module (SPM-5.5)
Function: Spindle Drive / Spindle Amplifier
Suitable System: FANUC 16i, 18i, 21i series (TA/MA)
Version: #H500 (Spindle Software Version)
Weight: 6.0 kg
Dimensions (L×W×H): 38.0 × 9.0 × 32.0 cm
Input Voltage: 283–325 VDC
Rated Power: 6.8 kW
Output Voltage: Max. 230 VAC
Rated Output Current: 27 A
Interface Type: Type 1 (Standard Interface)
Cooling Method: Forced air cooling
Protection: Over-voltage, over-current, over-temperature, short-circuit protection
Compatible Motors: A6, AP8 series & high-speed AC spindle motors
Feedback Sensors:
M sensor (Position coder / Magnetic sensor for orientation)
MZ sensor, BZ sensor (Built-in motor type)
Incremental encoder (INC) support
High precision spindle speed & torque control
Suitable for CNC milling, drilling, grinding, machining centers
Industrial automation & robotic applications
Rugged design for harsh industrial environments
BRK safety function & stable SLK/TPR shaft design
Compatible with standard FANUC alpha series feedback systems
#H500: Specifies internal spindle software version
Alternative: A06B-6078-H206#H501 (different firmware)
PCB Boards: A16B-2202-0431, A16B-2202-0681
